SamtecTSW-110-17-G-DConnector Headers and PCB Receptacles

Use this unshrouded TSW-110-17-G-D connector from Samtec when board-to-board interconnects is required. This HDR connector's 20 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. It has a maximum voltage rating of 550 VAC. This is a 2-row connector. Its pitch is 2.54 mm. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 25.4 mm long, 18.28 mm tall and 5.08 mm deep. TSW-110-17-G-D is housed in black polyester.
