| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8541.29.00.95 |
| Automotive | No |
| PPAP | No |
| Configuration | Quad |
| Channel Mode | Enhancement |
| Channel Type | N|P |
| Number of Elements per Chip | 4 |
| Maximum Drain-Source Voltage (V) | 200 |
| Maximum Drain-Source Resistance (mOhm) | 10000@10V@N Channel|12000@10V@P Channel |
| Typical Input Capacitance @ Vds (pF) | 52@25V@N Channel|54@25V@P Channel |
| Typical Fall Time (ns) | 15(Max) |
| Typical Rise Time (ns) | 15(Max) |
| Typical Turn-Off Delay Time (ns) | 20(Max) |
| Typical Turn-On Delay Time (ns) | 10(Max) |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Operating Temperature (°C) | 150 |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 0.88 |
| Package Width | 4 |
| Package Length | 4 |
| PCB changed | 12 |
| Standard Package Name | DFN |
| Supplier Package | DFN EP |
| Pin Count | 12 |
| Lead Shape | No Lead |
