Product Technical Specifications
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
Automotive
No
PPAP
No
Contact Arrangement
SPDT
Contact Form
1 Form C
DC Coil Voltage (V)
12
Coil Current (mA)
33
Coil Resistance (Ohm)
360
Maximum AC Switching Voltage (V)
250
Maximum DC Switching Voltage (V)
250
Maximum Switching Current (A)
16
Operate Time (ms)
7
Release Time (ms)
3
LED Indicator
No
Push to Test Button
No
Coil Suppression Diode
No
Relay Construction
Non-Latching
Mounting
Through Hole
Termination Style
PC Pin
Number of Terminals
8
Minimum Operating Temperature (°C)
-40
Maximum Operating Temperature (°C)
85
Package Type
DIP
Product Weight (g)
15.7
Product Length (mm)
29
Product Depth (mm)
12.7
Product Height (mm)
15.7
